What Is Thermogravimetric Moisture Analysis?
The moisture content influences the weight, density, viscosity, refractive index, and electrical conductivity of a material. Methods for testing moisture content tend to exploit one or more of these physical or chemical properties. Direct measurements address the presence of water itself, either through its removal or through chemical interaction. The use of a thermogravimetric moisture analyzer is a way to directly measure the moisture content of a sample by using the loss on drying (LOD) technique. LOD measures the weight of a sample before and after a drying procedure and uses the weight delta to determine the percentage of moisture as the weight removed by the drying process in comparison to the initial weight of the sample.
Typically, this process is done in a drying oven with a balance to determine the initial and final weight of the sample and using a simple mathematical calculation to determine the moisture content ([initial weight – end weight]/initial weight). This process typically takes several hours to complete and is vulnerable to user error. A moisture analyzer works on the same principle but is an automated system that employs a microprocessor-controlled heating element and an analyzer all in one device; by using such a device, the moisture content of a sample can be measured in minutes rather than hours.
Analis is distributor of Ohaus moisture balances and balances for Belgium, the Netherlands and Luxembourg.
Analis is distributor of Memmert Ovens and Incubators for Belgium, the Netherlands and Luxembourg.
Discover our solutions:
Our products
Faster, Smarter, and More Efficient Moisture Analysis
You can analyze more samples using the MB120, retrieve data that has been recorded, and spend more time utilizing your findings rather than preparing.
Everything we use on a daily basis is impacted by moisture. As a result, being able to precisely ascertain the moisture content of samples is frequently crucial. Our flagship moisture analyzer, the MB120, is capable of handling both simple and complex readings, making the procedure easier, faster, and more effective overall. You can analyze more samples using the MB120, retrieve data that has been recorded, and spend more time utilizing your findings rather than preparing.
Applications
Percent Moisture Determination, Percent Moisture Regain Determination, Percent Solid Determination, and Weighing
Display
4.3" TFT color touchscreen display
Operation
Power cord (included)
Communication
RS232 with GLP/GMP data output, USB Host and USB Device (included)
Construction
Metal base, ABS top housing, halogen heat source, stainless steel pan support, stainless steel pan handler, in-use cover
Design Features
Seven shut-off criteria (manual, timed, autofree %/s, autofree mg/s, A30, A60 and A90), four drying profiles (standard, fast, ramp and step), storage up to 100 methods and 1000 test results for all methods, user guide, 40°C to 230°C heating temperature range (1°C increments), 14 operational languages
Simple Operation. Precise Results.
Measuring moisture content has never been easier than with the MB90 Moisture Analyzer. The MB90's halogen heating distributes heat uniformly over the sample and speeds up the drying process, delivering fast and precise measurements.
Benefits:
- Halogen heating increases efficiency for faster results.
- Intuitive touchscreen menu offers step-by-step guidance for any application.
- Tool-free cleaning for easy maintenance.
Design Features:
Three shut-off criteria (manual, timed or auto), two drying profiles (standard and fast), storage up to two methods, user guide, 40°C to 200°C heating temperature range (1°C increments), 14 operational languages
Specifications:
Maximum capacity : 90.00 g
Pan diameter : 90.000 mm
Construction:
Metal base, ABS top housing, halogen heat source, stainless steel pan support, stainless steel pan handler, in-use cover.
Applications:
Percent Moisture Determination, Percent Moisture Regain Determination, Percent Solid Determination, and Weighing.
Outstanding Performance, Flexible Configuration and Reliable Results
The new OHAUS MB27 Basic Moisture Analyzer combines high quality and durable construction into a sleek, compact design. The MB27 offers dependable, accurate results for a wide variety of moisture analysis applications.
Benefits :
- With 0.01% 0.001g accuracy, the MB27 Moisture Analyzer is suitable for most applications.
- Halogen heating and dual weight-temperature calibration provide fast, reliable results.
- User-friendly touch-button design for easy operation.
Applications :
Percent Moisture Determination, Percent Solid Determination, and Weighing
Outstanding Performance, Flexible Configuration and Reliable Results
The MB25 provides precise moisture content determination at an unbeatable value. With a large backlit LCD display, standard RS232 port, 110g capacity with a readability of 0.005g/0.05% and halogen heating, the MB25 offers moisture analysis for any budget.
Applications
Percent Moisture Determination, Percent Solid Determination, and Weighing
Display
Backlit liquid crystal display (LCD)
Operation
Power cord (included)
Communication
RS232 (included)
Construction
Halogen heat source, ABS housing, metal pan support, metal pan handler, in-use cover
Design Features
3 shut off criteria (manual, timed or auto), 1 standard heating profile, 50° to 160° C heating range (5° C increments)
Outstanding Performance, Flexible Configuration and Reliable Results
The MB23 provides precise moisture content determination at an unbeatable value. With a large backlit LCD display, standard RS232 port, 110g capacity with a readability of 0.01 g/0.1%0.01 g/0.1%, and an non-glass infrared heating element, the MB23 offers moisture analysis for any budget.
Benefits :
- Glass-less infrared heating increases efficiency for faster results.
- User-friendly touch-button design for easy operation.
- Compact design suits any workspace.
Applications :
Percent Moisture Determination, Percent Solid Determination, and Weighing.
