There are parallel reactions stations for applications such as heating, cooling, condensing, work up, evaporation, inerting, filtration, catalyst screening, leaching, polymer research, process development, refluxing and stirring.
Parallel Reactor Systems - Xelsius reaction system
A compact and fast reactor with 10 completely individually tempered and stirred reactor cells in the temperature range from -20°C to +150°C. This system is suitable for parallel synthesis, temperature studies, crystallization analysis, solubility profiling, flow chemistry, reaction and process optimization as well as for performing DoE (Design of Experiment) studies.
|
• Wide temperature range -20°C to +150°C • Different stirring rate in each vial • Long lifetime reaction cell • Ergonomic and small footprint • Overheat Protection for safety operation • Very intuitive and user-friendly • Interface Independent control of all parameters for each cell | • PTFE coated surface resistant to aggressive acids/solvents • Live monitoring of flow and temperature on graphical display • Temperature stability and accuracy of 0,1°C • Gloves sensitive touch screen • Flexibility of operation under fume hood or outside on bench-top surface |
MYA 4 Reaction Station
A 4-zone reaction station offering safe and precise heating, active cooling, software control and data-logging for 24/7 unattended chemistry
|
FLEXIBLE AND VERSATILE • 4 different zones, each with heating and active cooling • Use one compact system for a range of experiments • Precise temperature control • Magnetic or optional overhead stirring • Accepts a wide range of vessel sizes and styles • Control your experiments and log results automatically • Use Mya 4 with or without a chiller |
SAFER, CLEANER, GREENER, MORE PRODUCTIVE • Replace inefficient, messy and unsafe oil and ice baths • Save space compared with separate reaction set-ups • Software control improves safety, reduces manual errors, and allows 24/7 unattended chemistry, for improved productivity • Integrate 3rd party devices such as pumps, balances and pH sensors etc. |
Carousel Reaction Stations
Simultaneously heats, stirs and refluxes multiple samples under an inert atmosphere.
| CAROUSEL 6 PLUS • Accepts round bottom flasks, including vessels with one or two sidearms: 5ml up to 250ml • Powerful, even stirring – fits on a 135mm Carousel stirring hotplate • Rapid heating up to 180°C with full visibility of flask contents during experiments • Water cooled aluminium reflux head • Easy-on PTFE caps feature a quick thread for fast attachment and a valve to perform reactions under inert atmosphere • Cooled option to perform up to six cooled reactions to -78°C • Integrates with Tornado overhead stirring for powerful stirring of viscous samples Read more Watch video | CAROUSEL 12 PLUS • Accepts up to 12 glass tubes with a reaction volume from 1ml to 20ml • Powerful, even stirring – fits on a 135mm Carousel stirring hotplate • Rapid heating up to 220°C and cooling to -78°C • Removeable water cooled aluminium reflux head • Easy-on PTFE caps feature a quick thread for fast attachment and a valve to perform reactions under inert atmosphere • Good visibility of tube contents • Fluoropolymer coating makes the Carousel 12 resistant to chemicals and easy to clean Read more Watch video |
High pressure multiple reactor systems
Apply the principles of high throughput experimentation to reactions conducted at elevated temperatures and pressures.
| PARR MRS 5000 – MULTIPLE REACTOR SYSTEM • Six 45ml or 75ml reactors with internal stirring. • Operating pressures up to 200 bar. • Operating temperatures to 300 °C. • Individual temperature control per reactor. • Continuous individual pressure monitoring. • Computer control and data logging. • Manifold system for rapid turn around and to allow two different input gases. • Volumes and reactor geometry designed for three phase reactions. • Flexible Control Software. Read more | PARR MBS 2500 – MICRO BATCH REACTOR SYSTEM • Three reactors with 5 mL or 10 mL volume, available in stainless steel, high-nickel alloys, titanium, zirco¬nium, and other exotic materials • Small 10” x 12” (25 cm x 30.5 cm) footprint, with remotely located 4848-based controller for temperature/stirring control and pressure display. • Standard 200 bar @ 300 °C rating in T316 Stainless Steel • Trusted Parr seal geometry employing either a captive PTFE flat gasket and screw cap with compression bolts, or a self-sealing O-ring with tool-free screw cap closure • Standard head fittings to include safety rupture disc, pressure transducer, inlet/vent valve, and internal thermocouple • 3-valve inlet manifold for control of gas addition Read more |
