  1. Centrifugation Benchtop centrifuges
  2. Sigma 3-16T, laboratory benchtop centrifuge, 100-240 V, 50/60 Hz
Share
SIGMA

Sigma 3-16T, laboratory benchtop centrifuge, 100-240 V, 50/60 Hz

Reference: SIG-100018

https://www.analis.com/web/image/product.template/139066/image_1920?unique=926f541
The Sigma 3-16T laboratory benchtop centrifuge is a powerful and versatile centrifuge designed for routine and advanced applications in life science, clinical diagnostics, biotechnology and research laboratories.

An IVD-certified version of the Sigma 3-16T is also available for clinical diagnostic applications (Ref. SIG-100023).

With a maximum speed of 15,800 rpm and RCF up to 23,723 × g, it delivers reliable performance for a wide range of laboratory separation tasks. Its compact footprint and high capacity make it an ideal all-round centrifuge for everyday laboratory workflows.

Its compact design and broad rotor portfolio allow the centrifuge to process a wide variety of tubes and microplates, ensuring high versatility for many laboratory protocols. The intuitive Spincontrol T touchscreen controller simplifies operation, supports programmable methods and enables run data export via USB for documentation and traceability.

Advanced safety features such as automatic rotor identification, imbalance monitoring and rotor life cycle tracking ensure reliable operation and user protection. The centrifuge also includes energy-saving ECO mode and quality management functions to support modern laboratory requirements.

Key features of Sigma 3-16T

  • Maximum speed: 15,800 rpm | Max. RCF: 23,723 × g | Max. capacity: 4 × 400 ml (swing-out rotor)
  • Spincontrol T touchscreen controller with up to 99 programmable methods
  • USB interface for run data export and documentation
  • Wide range of fixed-angle and swing-out rotors and adapters
  • Automatic rotor detection and rotor life monitoring
  • Sensor-based digital imbalance monitoring system
  • Quiet operation and compact footprint
  • Energy-saving ECO mode and quality management features
These features make the Sigma 3-16T a reliable solution for sample preparation, cell culture work, blood and urine analysis, microplates, molecular biology workflows and general laboratory centrifugation. Thanks to its high capacity and broad rotor compatibility, the Sigma 3-16T supports many laboratory protocols in research, diagnostics and industrial laboratories.

Need help choosing the right rotor or configuration?

Contact our specialists or download the brochure below for full specifications and accessories.

    This combination does not exist.

    Technical information


    Specification Sigma 3-16T
    Maximum capacity Swing-out rotor: 4 × 400 ml
    Maximum RCF 23,723 × g
    Maximum speed 15,800 rpm
    Minimum speed 100 rpm
    Noise level (approx.) 64 dB(A) fixed-angle rotor
    Power consumption 1,000 W
    Dimensions (H × W × D) 337 × 460 × 521 mm
    Height with open lid 755 mm
    Weight (without rotor) 50 kg

    Related documents

    DOCUMENT NAME

    RELEASE DATE

    DOWNLOAD

    Brochure Sigma 3-16T & 3-17KT EN
    18 / 03 / 2026
    Download icon Download
