SYSTEC

Systec DX-45 Horizontal, front-loading autoclave

Reference: SYS-1945

• Fully automatic, microprocessor control including 12 programs:
1-3 Solids
4-5 Waste destruction bags
6-7 Liquid waste
8-11 Liquid Media
12 Cleaning
• Integrated separate steam generator (no heating elements in sterilization chamber)
• Novel safety ring-lock closure system with lip seal
• Temperature and steam pressure up to 140°C / 4 bar absolute pressure
• Thermal lock: door lock controlled by pressure and medium temperature according to Pressure Vessel Regulations
• Flexible PT-100 temperature sensor for reference vessel
• Medium temperature-controlled sterilization time
• Electronic pressure transducer for pressure and temperature control
• "Autofill" - Automatic demineralized water feed for steam generation
• Special program for waste destruction with pulsating heat-up period for improved ventilation of waste bags
• Start by clock / timer for programmed start time
• Steam exhaust condensation, water cooled, thermostatic controlled
• Common collector connection for all outlets
• Emptying valve
• Base plate for vessels, baskets etc.
• Validation port
• RS 232 interface for external data transfer
• Prepared for subsequent printer installation
• Prepared for subsequent rapid cooling installation
• Prepared for subsequent installation of vacuum system
• Prepared for subsequent drying installation
• Safety cut of at low water level
• Safety cut of at excess temperature

Request more information

Systec DX-45 Horizontal, front-loading autoclave

Technical information

Connections:
Electrical connections: 220 - 240 V single phase (16A)
Demineralized water: 3/4" stopcock for tube connection
Process water (tap water): 3/4" stopcock for tube connection
(for exhaust vapor condensation; apparatus can also be operated without this)
Drain: 3/4" tube connection; max. 400 mm from floor or floor drain (siphon).

Systec DX-45 Horizontal, front-loading autoclave

Reference: SYS-1945

Technical information
