Advanced microscope system for automated technical cleanliness and particle analysis.
The Olympus / Evident CIX100 delivers fast, reliable inspection and classification of particulate contamination on components.
- Compliant with ISO 16232 and VDA 19 cleanliness standards
- High-resolution optics and advanced image processing for accurate particle detection
- Automates counting, sizing, and classification of contaminants
- Integrated database and reporting for full traceability
- Ideal for automotive, aerospace, and precision engineering
Analis provides setup and support for compliance-critical applications across Benelux.
Compact inverted microscope for efficient cell culture workflow and live cell observation.
The Olympus / Evident CKX53 is designed to optimize usability and image quality in tissue culture labs.
- Precentered phase contrast and inversion contrast (IVC) for clear 3D-like images
- Integrated fluorescence slider (3-position) for basic fluorescence work
- Compact, ergonomic frame saves bench space and supports rapid cell checks
- Detachable condenser enables viewing of tall flasks up to 190 mm
- Accommodates a wide range of cell culture containers
A reliable tool for everyday cell culture. Analis can help adapt it to your specific workflow.
Fast, simultaneous carbon and nitrogen analyses
The CN 802 is a robust, flexible combustion analyzer that follows official reference methods to determine carbon and nitrogen across many sectors: agriculture, environmental, food & feed and chemical.
The proprietary CNSoft™ software powers the CN 802 and delivers unsupervised, simultaneous results in 5 minutes for:
- TC: Total Carbon
- TOC, TIC: Total Organic and Inorganic Carbon (after acidification)
- TN: Total Nitrogen
- C/N Ratio
The CN 802 is a safe analyzer with no aggressive chemicals or time-consuming steps: just prepare your sample and walk away.
Set your next analysis and get a wealth of information from the sample.
CN 802 Working Process
The sample is purged with a carrier gas and drops into the combustion reactor, where it is converted into elemental compounds at high temperature (above 1000 °C).
Water is separated in two steps. The combustion gases first reach the maintenance-free physical trap DriStep™ (WT1) after combustion, trapping 99% of the water; a chemical trap (WT2) then removes the remaining 1%.
High temperature combined with the exclusive Vcopper™ reduces nitrogen dioxide to molecular nitrogen in the reduction furnace.
The VELP HighSensIR detector covers a very wide carbon range, from a few ppm up to 150 mg of absolute carbon — from micro to macro applications.
Auto-regenerating CO2 absorbers then trap carbon dioxide, letting the exclusive TCD (Thermal Conductivity Detector) measure the nitrogen content.
Fat extraction for fiber determination
The COEX is used to perform preliminary defatting of the sample prior to fiber determination with FIWE and FIWE Advance. The COEX guarantee maximum reliability and is a mandatory step for all feed sample with high fat content.
The efficient pump aspirates and removes the fatty component that will be collected in a dedicated waste tank/bottle.
The COEX is easy to use and convenient, all the reagents can be added through the same channel.
Avoid sample loss and transfers
The COEX ensures rapid fat extraction directly into the same glass crucibles used by the FIWE and FIWE Advance whenever the fat content of feed sample is high and need to be reduce to less than 1%.
The crucible containing the defatted sample is transferred directly to the FIWE and FIWE Advance analyzer eliminating possible errors due to sample transfer.
Portable Particle Counting for Cleanroom Classification and Environmental Monitoring
Key Benefits
- Accurate particle detection from 0.3 µm to 25 µm across multiple size channels
- Portable and ergonomic design for flexible, multi-location monitoring
- Real-time measurement and data logging for fast decision-making
- Compliance-ready reporting aligned with ISO 14644 and GMP requirements
- User-friendly touchscreen interface, suitable for operation with gloves
- Designed for routine monitoring and validation workflows
Typical Applications
- Cleanroom classification and routine monitoring (pharma, biotech, medical devices)
- Indoor air quality (IAQ) assessment and HVAC validation
- Controlled production environments (electronics, food, aerospace)
- Environmental monitoring and contamination control
Accessories and Configuration
- Isokinetic probe
- Temperature and humidity sensor
- Calibration certificate
- Data management software
- Battery and power supply
- Thermal printer
- Carrying case
- External battery charger
Get Expert Advice or Request a Quote
Rapid and efficient filtration
CSF6 is optimal for efficient filtration, after the samples have been processed by the Enzymatic Digester GDE.
This VELP combination allows the analysis to be carried out in accordance with the official AOAC (Determination of Total Dietary Fibre) method with a drastic reduction in the time required compared to the manual procedure.
CFS6 filtration unit is able to perform single or multiple samples at the same time, up to a maximum of 6 samples at the same time, in less than 20 minutes, even at full load.
Reliable filtration unit
The high efficient pump allows to speed-up the filtration step and the final washing.
Compressed air can be also injected from the bottom to remove any sample accumulated in the filter of the crucible, which affects the quality of filtration.
The CTX Texture Analyzer is AMETEK Brookfield's new advanced model for the compression/tension testing of materials. It brings an exciting new dimension of quick, efficient testing to busy labs that need to improve productivity while maintaining quality.
The CTX usability features allow for easy setup to get you up and running quickly. Whether you are testing the consistency of pills and tablets, the peel ability of a yogurt lid, or the tensile strength of lipstick, our new CTX will meet your ever-growing testing needs.
The addition of TexturePro Software makes the CTX ideal for R&D labs performing material evaluation/characterization tests. It is also great in QC applications where data can be sent or saved in multiple formats.
FEATURES & BENEFITS
- Provides a "real life" insight into physical properties.
- Interchangeable load cells for optimal flexibility (eight choices ranging from 100g to 100kg).
- Easy-to-read display and easy-to-use intuitive controls.
- Extended boom travels up to 280mm for longer reach testing.
- High Precision: 500 Hz data output rate captures the precise moment there is a change to your sample.
- The choice of three adjustable base tables allows for the versatility of sample testing.
- 21CFR compliant with optional TexturePro Software.
APPLICABILITY and OPTIONAL ACCESSORIES
The CTX has a wide variety of probes, fixtures for testing broad categories of packaging materials, foods of all types, cosmetics, pharmaceuticals, and mechanical devices. AMETEK Brookfield can also custom design a fixture and probe for most applications.
- TexturePro Software
- Temperature Probe
- Bubble Level
- Calibration Weight Set
- Gelatin Bath System for gel conditioning Bloom Jar - industry approved
Durable and user-friendly upright microscope designed for classroom use.
The Olympus / Evident CX23 offers intuitive operation and high optical performance for educational environments.
- Built-in safety features and ergonomic design for student use
- Clear, bright optical performance with LED illumination
- Lightweight and easy to transport or store
- Ideal for biology, life sciences, and microscopy training
- Designed for long-term durability in school settings
Perfect for educational labs in Benelux. Contact Analis for educational packages.
Routine upright biological microscope optimized for education, lab research, and diagnostics.
The CX43 and CX33 from Olympus / Evident combine user-friendly operation with reliable optical performance.
- Ergonomic frame allows for efficient long-session observation
- Bright LED illumination with long life and consistent intensity
- Optional fluorescence light source (470 nm) for basic applications
- Modular design supports digital imaging and documentation
- Ideal for training, routine analysis, and lab teaching
A reliable platform for institutions and labs. Reach out to Analis for local support and configuration.
Esco’s Cytoculture® Cytotoxic Safety Cabinet is the premium solution for cytotoxic/antineoplastic drug processing; providing the highest level of patient, pharmacist, and environmental protection. This revolutionary product builds on Esco’s experience of more than 20 years as a global leader in biological safety containment technology.
The unique demands of handling and preparing cytotoxic drugs for use in chemotherapy require a specialized cabinet. With this in mind, Esco has developed a highly specialized cabinet designed especially for the preparation of these potentially dangerous drugs.
Key Benefits:
Safe filter changing
Safer dual exhaust filters
HEPA certified to EN 12469
The DK 18/26 Series Kjeldahl digestion unit with aluminium heating block ensures high thermal homogeneity heating up to 450 °C. The temperature of the block is constantly controlled by a microprocessor and is extremely stable, homogeneous and precise: ±0.5°C at all selectable temperatures.
The DK 18/26 Series guarantees accuracy and repeatability. The DK 18/26 performs batch digestion of up to 18 samples with 100 ml test tubes - Ø 26 mm, reducing the energy consumption (-13% compared to the previous series). Low energy consumption provides lower costs of analysis and limits CO2 release.
For applications where the digestion process produces fumes, acid gases or corrosive substances, the below specific accessory is strongly recommended:
- KS 1000 Scrubber neutralizes all the fumes
The DK 20 Series Kjeldahl digestion unit with aluminium heating block ensures high thermal homogeneity heating up to 450 °C. The temperature of the block is constantly controlled by a microprocessor and is extremely stable, homogeneous and precise: ±0.5°C at all selectable temperatures.
The DK 20 Series guarantees accuracy and repeatability. The DK 20 series perform batch digestion of up to 20 samples with 250 ml test tubes - Ø 42 m, reducing the energy consumption (-13% compared to the previous series). Low energy consumption provides lower costs of analysis and limits CO2 release.
For applications where the digestion process produces fumes, acid gases or corrosive substances, the below specific accessory is strongly recommended:
- KS 1000 Scrubber neutralizes all the fumes
